$495.00
Revel W553L In-wall multi-purpose home theater speaker - W553L—
$495.00
The Story
Two 5" Micro-Ceramic Composite (MCC) Cone, Cast-Aluminum Frame Woofers
Can be mounted Vertical or Horizontal for L-C-R applications
1" aluminum dome swiveling tweeter with waveguide
Nominal impedance: 8 ohms
Recommended amplifier power range: 10- 150 watts
Sensitivity (2.83V/1m): 91 dB
Frequency Range -3 dB from 50Hz-25kHz; -10dB from 35-35kHz
3-position HF level control
Mounting depth: 2.9" (7.4 cm)
Weight: 6.6 lb / Shipping weight: 7.7 lb (3.5 kg)
Cutout dimensions (H x W): 14.1" x 6.4" (35.9 cm x 16.3 cm)
Includes zero-bezel magnetic grille
Grille finished dimension (H x W): 15.1" x 7.4" (38.4 cm x 18.8cm)
C-2 fastening mechanism
Compatible with wall material thickness range: 0.5" “ 2.0" (1.3 cm “ 5.0 cm
Can be mounted Vertical or Horizontal for L-C-R applications
1" aluminum dome swiveling tweeter with waveguide
Nominal impedance: 8 ohms
Recommended amplifier power range: 10- 150 watts
Sensitivity (2.83V/1m): 91 dB
Frequency Range -3 dB from 50Hz-25kHz; -10dB from 35-35kHz
3-position HF level control
Mounting depth: 2.9" (7.4 cm)
Weight: 6.6 lb / Shipping weight: 7.7 lb (3.5 kg)
Cutout dimensions (H x W): 14.1" x 6.4" (35.9 cm x 16.3 cm)
Includes zero-bezel magnetic grille
Grille finished dimension (H x W): 15.1" x 7.4" (38.4 cm x 18.8cm)
C-2 fastening mechanism
Compatible with wall material thickness range: 0.5" “ 2.0" (1.3 cm “ 5.0 cm
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
Two 5" Micro-Ceramic Composite (MCC) Cone, Cast-Aluminum Frame Woofers
Can be mounted Vertical or Horizontal for L-C-R applications
1" aluminum dome swiveling tweeter with waveguide
Nominal impedance: 8 ohms
Recommended amplifier power range: 10- 150 watts
Sensitivity (2.83V/1m): 91 dB
Frequency Range -3 dB from 50Hz-25kHz; -10dB from 35-35kHz
3-position HF level control
Mounting depth: 2.9" (7.4 cm)
Weight: 6.6 lb / Shipping weight: 7.7 lb (3.5 kg)
Cutout dimensions (H x W): 14.1" x 6.4" (35.9 cm x 16.3 cm)
Includes zero-bezel magnetic grille
Grille finished dimension (H x W): 15.1" x 7.4" (38.4 cm x 18.8cm)
C-2 fastening mechanism
Compatible with wall material thickness range: 0.5" “ 2.0" (1.3 cm “ 5.0 cm
Can be mounted Vertical or Horizontal for L-C-R applications
1" aluminum dome swiveling tweeter with waveguide
Nominal impedance: 8 ohms
Recommended amplifier power range: 10- 150 watts
Sensitivity (2.83V/1m): 91 dB
Frequency Range -3 dB from 50Hz-25kHz; -10dB from 35-35kHz
3-position HF level control
Mounting depth: 2.9" (7.4 cm)
Weight: 6.6 lb / Shipping weight: 7.7 lb (3.5 kg)
Cutout dimensions (H x W): 14.1" x 6.4" (35.9 cm x 16.3 cm)
Includes zero-bezel magnetic grille
Grille finished dimension (H x W): 15.1" x 7.4" (38.4 cm x 18.8cm)
C-2 fastening mechanism
Compatible with wall material thickness range: 0.5" “ 2.0" (1.3 cm “ 5.0 cm
